Pintech DK-2000 (150KHz,2000A) Flexible current probe

Pintech DK-2000



FLEXIBLE CURRENT PROBE Especially for AC current testing Bandwidth : 150KHz Max .measuring current : 2000A Coil circumference : 300mm Cable length (from box to coil) : 2 .5m Coil cross section (max) : 3mm

Pintech DK-2000 Specification

Type Sensitivity mV/A Peak peakCurrent(A) Measurement from noise mV Peak di/dt kA/µs Bandwidth(3db) Accuracy
DK-2000 2 2000 35A 10 20.0 50hz-150KHz 2%

Coil circumference:300 mm
Coil cross section(max):1KV
Temperature Range:-20?-100?
Cable length(from box to coil):2 .5m
Integrator box dimensions:H=160mm ,W=80mm,D=28mm
Coil cross section (max):3mm
Power supply:DC SUPPLY ADAPTOR 6V or Battery 4*AA
