Pintech PT-2720 (300KHz,0.4A-200A) AC/DC current probe

Pintech PT-2720



Bandwidth : 300KHz Current range : 0.4A-200A Attenuation ratio : 50mV/A,5mV/A Accuracy : 2%

Pintech PT-2720 Specification

Detailed description :
Model Number PT-2720
Range 50mV/A 5mV/A
Current range DC: 0.4A~10AAC:0.4A~10Ap-p DC: 10A~100AAC:10A~200Ap-p
Output signal error 2% 2%
Bandwidth(-3dB) DC~300kHz
Load impedance =1MO and =100pF
Impedance 0.01O
Noise 2mV
Rise time 1.2µs
Operating voltage Max.600Vrms
CMRR Max.600Vrms
Battery 9V (international delivery is forbidden,please buy it at local)
Low battery indicator with green LED light when >6.5V
Overload indicator Red LED light indicates the over measuring current, change the range
Mechanical Specifications
Operating temperature 0~+50?
Storage temperature ?
Temperature influence Every 10?,<0.2%
Operating relative humidity +10?~+30?:85±5% relative humidity(non-condensing )+40?~+50?:45±5%relative humidity(non-condensing )
Operating height 0~2000m
Max clam size Diameter 11mm
Dimension 231?36?67mm
Weight 310g(not including battery)
Output 2 meters of coaxial cable, with insulation BNC connector jack at the end
